How to delete the Retention lease on a azure devops build pipeline

Chili cucumber

So you've encountered the frustrating issue of not being able to delete your build pipeline due to the fact that each build has a retention lock? Maybe one of the following error codes?

TF900561: The following build cannot be deleted because it is marked as Retain Indefinitely

TF900561: The following build cannot be deleted because it is marked as Retain Indefinitely: Remove the Retain Indefinitely flag to allow deletion of this build.

A lot of threads have been started about this topic and there seems to be no real solution to it in the Azure Devops GUI.

One option is to delete each and every build one by one, but it sounds like a task for some code, right?

The issue

When you connect a release pipeline to a artifact, a retention policy is put on the build artifact which keeps you from deleting a build artifact for as long as the release pipeline's lease is active. This is in theory good, but what happens if you delete the release pipeline?

Well - it seems that the retention lease is not removed when you delete the release pipeline - and so the build pipelines artifacts are stuck in limbo, having retention sometimes forever.

The solution

I've googled the topic and could find no real solution for this in the GUI - so I decided to look at the REST API thats powering Azure Devops.

It turns out you can delete the retention lock via the rest API. Once the locks are free, we can delete the whole build pipeline through the GUI. Great!

So first off, create a new .NET 6 console app. The new top level features of .NET 6 makes it easy to write quick script-like apps.

Code

using Newtonsoft.Json;
using Newtonsoft.Json.Linq;
using System.Net.Http.Headers;

//Change this to true too perform the delete. If false it will only log the leases found.
const bool DryRun = false;

//The definition Id of the build pipeline you want to remove the locks from
const int BuildDefinitionId = 12;

//The Private Access Token to use to authenticate to Azure Devops. To create one, follow this article: https://docs.microsoft.com/en-us/azure/devops/organizations/accounts/use-personal-access-tokens-to-authenticate?view=azure-devops&tabs=Windows
const string AuthenticationPat = "";

//The name of your organization
const string OrganizatioName = "";

//The name of the project your build pipeline resides in
const string Projectname = "";

using (var client = new HttpClient())
{
    //Encode your personal access token
    var credentials = Convert.ToBase64String(System.Text.Encoding.ASCII.GetBytes(string.Format("{0}:{1}", "", AuthenticationPat)));

    client.BaseAddress = new Uri($"https://dev.azure.com/{OrganizatioName}/{ProjectName}/");
    client.DefaultRequestHeaders.Accept.Clear();
    client.DefaultRequestHeaders.Accept.Add(new MediaTypeWithQualityHeaderValue("application/json"));
    client.DefaultRequestHeaders.Authorization = new AuthenticationHeaderValue("Basic", credentials);

    //Check that the build pipeline we are targeting exists
    var response = await client.GetAsync($"_apis/build/builds?definitions={BuildDefinitionId}&statusFilter=completed&api-version=7.1-preview.7");

    if (response.IsSuccessStatusCode)
    {
        //Build pipeline exists. Go ahead and get all the leases connected to this pipeline
        var leasesUrl = $"_apis/build/retention/leases?api-version=6.1-preview&definitionId={BuildDefinitionId}";
        var leases = await client.GetAsync(leasesUrl);

        //Parse the resulting leases id to be used for additional API calls
        var leasesObject = JsonConvert.DeserializeObject<JObject>(await leases.Content.ReadAsStringAsync());

        var leaseIds =
            from p in leasesObject["value"]
            select (string)p["leaseId"];

        //Join the lease Ids to a string for use in the delete call
        var joinedIds = string.Join(", ", leaseIds.Select(x => x));

        Console.WriteLine($"Found {leaseIds.Count} leases. Proceding to delete: {DryRun}");

        //Delete all the leases in one call
        var deleteUrl = $"_apis/build/retention/leases?ids={joinedIds}&api-version=6.1-preview";
        var deleteResponse = await client.DeleteAsync(deleteUrl);

        if (deleteResponse.IsSuccessStatusCode)
        {
            Console.WriteLine($"Deleted all leases. Try to remove the build pipeline now.");
        }
        else
        {
            Console.WriteLine($"Deleted leases failed {deleteResponse.StatusCode}");
        }
    }
    Console.WriteLine($"No build pipeline found with id { BuildDefinitionId }");
}

After you've run this code go ahead and try to delete the build pipeline in the azure devops GUI.
